What is a DALI driver?
2021-03-29

DALI is an international standard for digital lighting control, the full name is, digital addressable interface standard. 24v dali driver and dali 12v constant voltage dimmable led driver are available in Smarts.


The communication speed of DALI is 1200bps, the maximum transmission distance is 300m, and the network can be formed by up to 64 short addresses or 16 group addresses. One host can control one or more slaves.


12v constant voltage dimmable led driver


The voltage on the DALI bus is 16V, the high level range is 9.5-22.5V, and the low voltage level is -6.5V-6.5V
DALI management commands: switch, dimming, lighting scene, status monitoring
1.switch: can switch the independent DALI electronic ballast group or all ballasts in the system
2.Dimming: used to adjust the brightness of the electronic ballast and lamp, the range is 0.1%-100%. In order to ensure the service life of the lamp, generally the lowest brightness in practical applications should not be less than 3%
3.Lighting scenes: 16 light scenes can be set and realized in a DALI system
4.state monitoring: used to display or obtain the state of electronic ballasts and lights

If you are looking for best led driver dali, feel free to contact us.
