12v 72w ip67 waterproof led power supply 12v 6a for USA and Canada
SMT-012-072VW power supply 12v with ETL file#: 500504 to meet with Canada and USA lighitng. Protections:Short circuit/Overload/Over temperature.SMT-012-072VW waterproof grade IP67, can replace SOSEN power supply to install in humid place
|
Features
IP67 design for indoor or outdoor installations
Cooling by free air convection
100% full load burn-in test
Products through cETL,ETL,CE,RoHS Certification 2 years warranty |
SPECIFICAION
| MODEL | SMT-012-072VW | SMT-024-072VW | |||
| OUTPUT | DC VOLTAGE | 12V | 24V | ||
| RATED CURRENT | 6.0A | 3.0A | |||
| CURRENT RANGE | 0~6.0A | 0~3.0A | |||
| RATED POWER | 72W | 72W | |||
| RIPPLE&NOISE(max) | 1.2V | 1.2V | |||
| voltage TOLERANCE | 12V±5% | 24V±5% | |||
| SETUP RISE TIME | 80ms/110,220VAC | 80ms/110,220VAC | |||
| HOLD UP TIME(Typ.) | 60ms/110,220VAC | 60ms/110,220VAC | |||
| INPUT | VOLTAGE RANGE | 90~135/170~265Vac | 90~135/170~265Vac | ||
| FREQUENCY RANGE | 50~60Hz | 50~60Hz | |||
| POWER FACTOR(Typ.) | |||||
| EFFICIENCY(Typ.) | ﹥84% | ﹥84% | |||
| AC CURRENT(Typ.) | 0.5A/110V,220VAC | 0.5A/110V,220VAC | |||
| INRUSH CURRENT (Typ.) | COLD START 30A/110,220VAC | ||||
| PROTECTION | Short circuit | Protection type:recovers automatically after condition is removed | |||
| Overload | overload protected@145-160% above peak rating | ||||
| Over temperature | Protection type:Shut down o/p voltage,re-power on to removed | ||||
| ENVIRONMENT | WORKING TEMP. | -30~+50℃ (Refer to output load derating curve) | |||
| WORKING HUMIDITY | 20~99% RH non-condensing(Waterproof) | ||||
| STORAGE TEMP.,HUMIDITY | -40~+80℃,10~99%RH | ||||
| SAFETY&EMC | SAFETY STANDARDS | UL, CE Mark(LVD, EMC), IP67 | |||
| WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC IP-GND:1.5KVAC | ||||
| EMC Test Standards | EN55015:2006;EN61547:1995+2000;EN61000-3-2:2006 | ||||
| EN61000-3-3:1995+A2:2005;EN61346-1:2001;EN61347-2-13:2006 | |||||
| NOTE |
1.All parameters NOT specially mentoned are measured at 110VAC, 220VAC input,rated load and 25℃ of ambient temperature. 2.Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&10uf parallel capacitor. 3.Tolerance:includes set up tolerance,line regulation and load regulation. |
||||
| Label |
 |
||||
 |
 |
 |
 |
Applicable lamp type
72w waterproof led power supply high efficiency>0.90,high PF>0.95.It is with short-circuit and overload protection for various types of lamps such as:led downlight,LED ceiling light,led closet light...
