waterproof CE ROHS Slim LED Driver 12V DC 24W with ip67 case

SMT-012-024VE  is 12vdc 24w Slim LED Driver ( SMT-024-024VE) is 24vdc led driver ip67 , Able to work with LEDCO LED strip lights.
  • Brand:

    SMARTS
  • Item No.:

    SMT-012-024VE
  • Payment:

    T/T, paypal, credit card, western union
  • Color:

    silver
  • Input Voltage:

    100-265vac
  • Output Voltage:

    12v / 24v
  • Output Current:

    2A / 1A
  • Working Mode:

    constant voltage
  • Dimming mode:

    non dimmable
  • Size:

    132×30×20mm (L*W*H)
  • Certification:

    CE,ROHS appr.
Products description

Waterproof CE ROHS Slim LED Driver 12V DC 24W with ip67 case


Model SMT-012-024VE  is a 12vdc waterproof led driver 24W, aluminum case IP67 for indoor and outdoor use, competitive with ECOPAC led driver 20w.


  Specification


model

SMT-012-024VE

SMT-024-024VE

Output

DC Voltage

12V

24V

Voltage Accuracy

±0.5V

±0.5V

Voltage Regulation

±0.5%

Rated current

2A

1A

Load Regulation

±1%

Rated power

24W

24W

Input

Voltage Range

100-265V AC

Frequency Range

4763HZ

Power Factor ( Typ.

70%@230V

70%@230V


Full Load EfficiencyTyp.

0.8@230V

 0.8@230V

AC CurrentTyp.

0.5A/220VAC

Inrush Current Typ.

 12A, 50% , 480us @220VAC

Leakage current

<0.50mA

Over temperature

100℃±10℃ shut down o/p voltage, automatically recover after cooling.

Short Circuit

Hiccpe mode,recovers automatically after condition is removed

Over Loading

≤120% Hiccup mode,recovers automatically after fault condition is removed

Over voltage

 ≦285VAC

Environment

Working TEMP.

-10+40℃

Working Humidity

2090%RH,non-condensing

Storage TEM.,Humidity

-20+70℃1095%RH

TEMP.coefficient

±0.03%/℃050℃

Vibration

10500Hz2G 10min./1 cycleperiod for 60min.

each along X,Y,Z  axes

Safety&EMC

Safety standards

 LVD

Withstand voltage

I/P-O/P:1.88KVAC

Isolation resistance

I/P-O/P100MΩ/500VDC/25℃/70%RH

EMC EMISSION

EMC IMMUNITY

Compliance to EN55015

Others

Weight

About 0.20Kg

Size

132×30×20mm (L*W*H)

packing

50PCS/CTN

Notes

1. All parameters NOT specially mentioned are measured at 110V/277VAC input , rated load and 25℃of ambient temperature.

2. Ripple& noise are measured at 20MHz of bandwidth by using a 12”t wisted

pair-wire terminated with a 0.1uf &47uf parallel capacitor.

3.  Tolerance:includes set us tolerance,line regulation and load regulation .

Click Send Email for Details
Click skpye 24 hours Online Reply
Scan to start our communication
Back to top


  Dimension

 LED Driver 12V


  Compatible LED light type


 This LED Driver 12V is non dimmable cosntant volatge type led drivers, 2 years warranty, input 100-265vac,  work with InvisiLED Pro 2 Tape Light.
